配置

安装含Matlab API的Madagascar过程详见Madagascar安装

写.rsf文件

下面的matlab程序提供了一个使用linear_events来合成一个水平地震事件的例子

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

function Linear(out)

% linear_events.m : downloaded from http://seismic-lab.physics.ualberta.ca/
d1 = linear_events(0.004,40,2,[0:10:10*79],1,0,1,2,2,2013);

% create header
rsf_create(out,size(d1)');

% write data
rsf_write(d1,out,'same');

在SConstruct中的调用如下：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

from rsf.proj import*
from rsf.prog import RSFROOT

########################################################################
# INITIALIZATION
########################################################################
matlab         = WhereIs('matlab')
matROOT = './'
matfun = 'Linear'
matlabpath = os.environ.get('MATLABPATH',os.path.join(RSFROOT,'lib'))

if not matlab:
    sys.stderr.write('\nCannot find Matlab.\n')
    sys.exit(1)

Flow('d',[os.path.join(matROOT,matfun+'.m')],
     '''MATLABPATH=%(matlabpath)s %(matlab)s
     -nosplash -nojvm -r
     "addpath %(matROOT)s;%(matfun)s('${TARGET}');quit"
     '''%vars(),stdin=0,stdout=-1)

End()

运行上述脚本SConstruct后生成的数据如下图所示

linear

读.rsf文件

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

function LinearWrite(in,out)

% read in size, delta of input header
% size: [n1 n2 n3 ...]
% delta: [d1 d2 d3 ...]
[sz, delta] = rsf_read_header(in);

% allocate space
d1 = zeros(sz);

% read in input data
rsf_read(d1,in,'same');

% generate another linear event
d2 = linear_events(0.004,40,2,[0:10:10*79],0.5,0.001,1,2,2,2013);

d = d1 + d2;

% create header
rsf_create(out,in);

% write data
rsf_write(d,out,'same');

对应的SConstruct如下

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

from rsf.proj import*
from rsf.prog import RSFROOT

########################################################################
# INITIALIZATION
########################################################################
matlab         = WhereIs('matlab')
matROOT = './'
matfun = 'LinearWrite'
matlabpath = os.environ.get('MATLABPATH',os.path.join(RSFROOT,'lib'))

if not matlab:
    sys.stderr.write('\nCannot find Matlab.\n')
    sys.exit(1)

Flow('d2',[os.path.join(matROOT,matfun+'.m'),'d'],
     '''MATLABPATH=%(matlabpath)s %(matlab)s
     -nosplash -nojvm -r
     "addpath %(matROOT)s;%(matfun)s('${SOURCES[1]}','${TARGET}');quit"
     '''%vars(),stdin=0,stdout=-1)

Plot('d2','grey wanttitle=n')

End()

生成的数据如下图所示


函数参数处理

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

% LinearPar函数多了一些数值型的参数dt,f0,tmax
function LinearPar(in,out,dt,f0,tmax)

% read in size, delta of input header
% size: [n1 n2 n3 ...]
% delta: [d1 d2 d3 ...]
[sz, delta] = rsf_read_header(in);

% allocate space
d1 = zeros(sz);

% read in input data
rsf_read(d1,in,'same');

% generate another linear event
d2 = linear_events(dt,f0,tmax,[0:10:10*79],0.5,0.001,1,2,2,2013);

d = d1 + d2;

% create header
rsf_create(out,in);

% write data
rsf_write(d,out,'same');

对应的SConstruct脚本如下

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

from rsf.proj import*
from rsf.prog import RSFROOT

########################################################################
# INITIALIZATION
########################################################################
matlab         = WhereIs('matlab')
matROOT = './'
matfun = 'LinearPar'
matlabpath = os.environ.get('MATLABPATH',os.path.join(RSFROOT,'lib'))

if not matlab:
    sys.stderr.write('\nCannot find Matlab.\n')
    sys.exit(1)

dt = 0.004
f0 = 40
tmax = 2

Flow('d3',[os.path.join(matROOT,matfun+'.m'),'d'],
     '''MATLABPATH=%(matlabpath)s %(matlab)s
     -nosplash -nojvm -r
     "addpath %(matROOT)s;%(matfun)s('${SOURCES[1]}','${TARGET}',%(dt)g,%(f0)g,%(tmax)g);quit"
     '''%vars(),stdin=0,stdout=-1)

End()

参考

https://github.com/ahay/src/blob/master/book/tccs/emdpf/
